- Size : M20 ~ M90 / 1/2“ ~ 3”

Catalog

No

'C'

'D'

Cable Dimensions

'E'

Metric

NPT

PF

'A'

Min Max

'B'

Min Max

E1FW 20S

20

1/2"

18

6.0 - 11.6

14.0 - 15.9

31

E1FW 20

20

1/2"

18

8.0 - 13.9

14.0 - 20.9

34

E1FW 25

25

3/4"

20

13.0 - 19.9

18.1 - 26.2

44

E1FW 32

32

1"

23

17.0 - 26.2

24.3 - 33.9

53

E1FW 40

40

1-1/4"

23

24.0 - 32.1

28.0 - 40.4

61

E1FW 50S

50

1-1/2"

23

30.0 - 38.1

38.0 - 46.7

67

E1FW 50

50

2"

25

36.0 - 44.0

43.0 - 53.1

78

E1FW 63S

63

2“

25

42.0 - 49.9

48.6 - 59.4

80

E1FW 63

63

2-1/2"

30

48.0 - 55.9

56.2 - 65.9

88

E1FW 75S

75

2-1/2"

30

52.8 - 61.9

60.2 - 72.1

104

E1FW 75

75

3“

30

55.0 - 64.0

61.0 - 78.5

110

E1FW 90

90

3“

30

68.0 - 79.3

81.4 - 90.4

127
